GDB SERIES
SEEKING’s GDB Series LED lights in garden focus on long-term stability and clean lighting along walkways, rather than decorative shapes that only work for a season. The appearance looks simple at first glance, but the metal structure and overall strength mean it can handle public environments without frequent service.
Power options include 30W / 40W / 50W / 60W with an efficiency up to about 130 lm/W, so most outdoor projects are able to replace old metal halide types directly. Most engineers usually check pole spacing first and then match the power level to get a reasonable lux on the ground.
The housing uses aluminum alloy and the whole body is built for rain and dust. With IP65 and IK08 protection, the luminaire manages rougher weather and the occasional impact during cleaning or maintenance work. The tool-free opening design also helps installers when the driver or wiring needs checking.
Typical applications include villa courtyards, residential walkways, city gardens, park pathways, commercial pedestrian streets, internal community roads and even station plazas, tourist zones or industrial park landscapes. Wherever people walk at night and a clean, modern appearance is needed, this LED garden light kit is a practical choice.
Model NO.
Power (W)
Luminous flux 130 lm/w
Light distribution curve
Above lumens based on 4000K Ra:80
The GDB Series is a pole-type LED garden lighting kit made for outdoor pathways, park areas, community spaces and general landscape illumination. Each unit contains the LED module, driver and mounting method so installers can connect directly to AC power on site.
Common places include villas, residential walkways, park routes, community gardens, commercial pedestrian paths, tourist spots, industrial parks and city squares. The IP65 and IK08 construction means it fits most outdoor projects.
Lower wattage such as 30W or 40W usually suits lower poles and short paths. Wider areas or taller poles often use 50W or 60W. Most lighting designers check pole height and pole spacing first, then choose the right option based on target illumination.
Yes, the efficiency can reach around 130 lm/W which is much higher than many legacy HID or CFL fixtures. In long running landscape projects this efficiency results in visible reduction in energy cost over time.
The GDB doesn’t push a sharp light point directly at pedestrians. Instead, the controlled optical design spreads light more evenly so people walking under the pole feel comfortable rather than being exposed to a strong spot beam.
The luminaire includes aluminum alloy housing with IP65 protection and IK08 impact rating. Once properly installed, the fitting handles rain, dust, and common outdoor conditions. For coastal or industrial environments SEEKING can provide advice about corrosion precautions.
Options include 3000K, 4000K, 5000K and 5700K. Residential projects often prefer 3000K, while parks, stations or commercial zones usually go for 4000K or 5000K to improve visibility.
The design target is L80B20 > 100,000 hours under standard operating conditions. SEEKING provides a 5-year warranty for normal use, giving project owners long-term confidence.
Yes, many installers replace older heads directly if the pole dimensions and mounting interface match. The GDB also accepts different accessories for situations where the pole type varies from one project to another.
The luminaire supports external control from timers, photocell circuits or central switching in the distribution board. For more advanced control or motion-based operation, customers normally share their specification and SEEKING matches the garden light kit to the required control method.
Discover the GDA Series LED Garden Light kit from Seeking – outdoor garden lighting for parks, paths and courtyards with 30W–60W options, up to 130 lm/W, IP65 & IK08 protection and anti-glare design for long-term use.
