LED Sports Lighting Stadium– High Mast LED Lighting by SEEKING

TFV SERIES

The TFV Series LED sports lighting stadium solution from SEEKING is built for large outdoor spaces where light quality, stability and long service life really matter. Designed as a high mast and stadium flood lighting system, the TFV Series is commonly used in sports venues, training grounds and high-pole installations that operate for long hours and under changing weather conditions.

With power options from 450W up to 1350W and an efficiency of up to 155 lm/W, the TFV Series provides strong, consistent illumination without unnecessary energy waste. The fixture uses a robust aluminum alloy housing and professional optical design to control glare while delivering light exactly where it is needed on the field.

Protection ratings of IP66 and IK08, combined with 10kV surge protection, make this LED sports lighting stadium fixture suitable for outdoor installations exposed to rain, dust and electrical disturbances. With a rated lifetime of L80B20 > 100,000 hours, the TFV Series is a long-term lighting choice for stadium operators and project owners who value reliability over frequent replacement.

Typical applications include football stadiums, multi-purpose sports fields, training centers, high-mast areas around arenas, and other large outdoor venues that require dependable, high-output LED lighting.

Technical Specifications:

AC Input100-277V 50/60Hz
Brand of LED DriverINVENTRONICS
Light Source3030 LEDs
CRI RangeRa>70
CCT RangeNW(4000K), CW(5700K)
Light Efficiency155 ± 5% Lumens per Watt (lm/W)
Beam Angle25° / 40°
HousingAluminum Alloy
Surge Protection10kV
WaterproofIP66 & IK08
L80B20@25℃>100000H
PF≥0.95 THD
CertificationsTUV, ENEC, CE, CB
Warranty5 Years
Light body colorWhite Aluminum( RAL 9006 )

Get Samples

TFV SERIES –LED Sports Lighting Stadium Parameter

Model NO.

XJ-TFV450W-*
XJ-TFV900W-*
XJ-TFV1350W-*

Power (W)

450
900
1350

Luminous Flux 155lm/W

69750
139500
209250

Light distribution curve

Above lumens based on 4000K Ra:70

TFV SERIES –LED Sports Lighting Stadium ProductSheet

Download

Need Help? Start Here..

Get Samples

FAQs – LED Sports Lighting Stadium – TFV Series

What is the TFV Series LED sports lighting stadium fixture used for?

The TFV Series is designed for large-scale outdoor lighting projects such as sports stadiums, football fields, training grounds and high-mast lighting areas. It provides powerful, focused illumination that meets the needs of professional and semi-professional sports venues.

Which wattage options are available in the TFV Series?

SEEKING offers the TFV Series in 450W, 900W and 1350W versions. Lower wattages are often used for training fields or smaller stadiums, while higher wattages are suitable for main stadiums, competition fields or high mounting heights.

How do I choose the right beam angle for my stadium project?

The TFV Series supports 25° and 40° beam angles. Narrow beams are usually selected for higher poles or long-distance lighting, while wider beams work well for lower mounting heights or broader coverage. Lighting simulations are often recommended before final selection.

Is this LED sports lighting stadium solution energy efficient?

Yes. With an efficiency of up to 155 lm/W, the TFV Series can replace traditional metal halide or older LED floodlights while significantly reducing power consumption and operating costs over time.

Can the TFV Series handle harsh outdoor weather?

The fixture is rated IP66 for water and dust protection and IK08 for impact resistance. This makes it suitable for outdoor stadiums exposed to rain, wind and airborne dust when installed correctly.

What kind of driver is used in the TFV Series?

The TFV Series uses a constant current LED driver from INVENTRONICS, known for stable output and long-term reliability. Each fixture also includes 10kV surge protection to guard against voltage spikes.

What colour temperatures are available?

Standard options include 4000K neutral white and 5700K cool white. Neutral white is often chosen for training fields and general stadium lighting, while cool white is preferred for high-visibility sports and broadcast environments.

How long is the service life of the TFV Series?

The TFV Series is designed with a rated lifetime of L80B20 over 100,000 hours at 25°C. In real projects, this means many years of operation with minimal lumen depreciation and reduced maintenance.

Is this product suitable for replacing existing stadium floodlights?

Yes. Many customers use the TFV Series as a retrofit solution to replace old metal halide or inefficient LED systems. As long as the mounting structure and electrical supply are compatible, upgrades can usually be completed with limited structural changes.

What warranty does SEEKING provide for TFV Series lighting?

SEEKING supplies the TFV Series LED sports lighting stadium fixtures with a 5-year warranty, covering manufacturing defects and providing peace of mind for long-term stadium and high-mast lighting projects.
